Chauvet Vesuvio RGBA

Vesuvio RGBA combines the ferocious intensity of a towering fog output with the visual impact of color mixed LED wash lighting to create dramatic atmospheric columns. Vesuvio RGBA outputs an impressive 40,000 cubic feet of fog per minute. It features a fast and dependable 1.6 kW heater and a 2.5 L fluid tank. It works best with the Chauvet HDF high-density and QDF quick dissipating fluid.

SPECIFICATIONS

Optical

• Light Source: 28 LEDs (7 red, 7 green, 7 blue, 7 amber) 2 W, (650 mA), 50,000 hours life expectancy

• Illuminance (total): 720 lux @ 5 m

• PWM Frequency: 977 Hz

Dynamic Effects

• Dimmer: Electronic

• Shutter/Strobe: Electronic

• Strobe Rate: 0 to 12.5 Hz

• Output: 40,00 cfm

• Low Fluid Shutdown: No

Construction / Physical

• Dimensions: 13.2 x 19.2 x 9.1 in (336 x 488 x 231 mm)

• Weight: 30 lb (13.6 kg)

• Exterior Color: Black

• Housing Material: Aluminum alloy

• Tank Capacity: 0.7 gal (2.5 l)

• Fluid Consumption: 82 ml/min

Connections

• Power Connection: Edison plug to Neutrik powerCON

• Power Input: Neutrik powerCON

• Data Connectors: 3- and 5-pin XLR

• Cable Length (power): 5 ft (1.5 m)

Control

• Control Protocol: DMX

• DMX Channels: 9

• Modes/Personalities: 1 personality

• On-Board Control: Yes

• Included Remote: No

Electrical

• Heat-up Time: 7 min

• Breaker Size: 15 A
